High Speed Running ZAY7045FG Drilling Milling Machine 7708801160mm Dimension

Model Number : ZAY7045FG

Certification : CE,ISO

Place of Origin : China

MOQ : 1 pieve

Payment Terms : L/C, D/A, D/P, Western Union, MoneyGram, T/T

Supply Ability : 200 pcs/month

Delivery Time : 10-20 days after received payment

Packaging Details : Standard export packaging

Name : ZAY7045FG Drilling And Milling Machine

Condition : New

Power(W) : 750W

Dimension(L*W*H) : 770*880*1160mm

Warranty : 1 Year

Weight : 320kg

Contact Now

High Speed Running ZAY7045FG Drilling Milling Machine 770*880*1160mm Dimension

Our drilling machine is of CNC control system, X, Y axis AC servo control and Z axis hydraulic feeding, so it realizes quick positioning and frilling. The drill has been awarded 2 patents of utility model, and is widely used for drilling of yoke plate and plate-like parts in steel constructions.
High Speed Running ZAY7045FG Drilling Milling Machine 770*880*1160mm Dimension

Model	ZAY7045FG
Max.drilling capacity	45mm
Max.face milling capacity	63mm
Max. end milling capacity	20mm
Taper of spindle bore	MT4 or R8
Max distance spindle-table	450mm
Mini distance spindle axis-column surface	260mm
travel of spindle	130mm
Head rotation	± 90 degree
Working table size	800*240mm
table travel (before and back)	175mm
table travel (left and right)	500mm
spindle speed step	6
Motor power	1.5kw
GW	370kg
Package size	670550860mm
NW	320Kg
